Modern datacentres run on layers of virtualisation, applications, networks, and security policies that all need to be monitored together, not in isolation. As environments scale, the real challenge is not deploying the technology—it’s keeping it healthy, stable, and predictable over time.

This is where VMware Aria comes in.

VMware Aria is VMware’s cloud management platform designed to give organisations complete visibility across their virtual and cloud environments. It brings together metrics, logs, network flows, capacity insights, and application dependencies into one integrated ecosystem. Instead of monitoring the environment through multiple tools, teams can use Aria to see the full picture: performance, behaviour, security, and dependencies.

Aria is made up of several components, but the three that directly support infrastructure monitoring are:

• VMware Aria Operations
• VMware Aria Operations for Logs
• VMware Aria Operations for Networks

In this blog, we’ll break down what each platform does, how it supports day-to-day operations, and how they work together to give you full-stack visibility.

This section outlines how monitoring will be implemented using the three VMware Aria Operations components:

1. VMware Aria Operations – Monitoring Design

VMware Aria Operations will act as the core monitoring platform for the virtual infrastructure. It collects performance metrics from vCenter, ESXi hosts, and virtual machines, and uses these metrics to evaluate health, performance, and capacity at every layer. Once deployed, the system continuously analyses CPU, memory, disk, and network usage trends to identify performance issues early. Aria Operations does not just present raw metrics; it builds baselines of typical behaviour and highlights deviations that may indicate future issues.

Aria Operations will be configured to pull detailed metrics from each vCenter Server. This includes host hardware status, VM performance counters, datastore capacity information, and cluster-level resource usage. These metrics enable capacity forecasting so teams can see when resources are likely to run out and plan expansions ahead of time. The forecasting engine also identifies oversized or undersized virtual machines, helping the operations team optimise resource consumption.

Dashboards in Aria Operations provide a structured way of monitoring the environment. For example, the Host Performance dashboard allows engineers to quickly identify issues such as high CPU Ready times or memory contention. The VM Troubleshooting dashboard brings together CPU, memory, I/O, and network graphs into one place, making it easier to trace the source of performance complaints. If required, custom dashboards can be created for critical applications or specific business units so their behaviour can be monitored more closely.

Alerts in Aria Operations will be based primarily on VMware’s recommended thresholds, but custom alerting rules will also be applied. For example, alerts may be configured at specific CPU Ready levels, datastore latency thresholds, or memory ballooning levels to match the organisation’s performance expectations. All alerts are designed to provide context and recommended actions, giving the operations team clear guidance on what needs attention. Alerts can also be escalated to service desk tools or email groups.

In addition to real-time monitoring, Aria Operations will support scheduled reporting. These reports include cluster capacity summaries, host performance over time, datastore growth trends, and VM rightsizing recommendations. The operations team can use these reports in monthly service reviews or capacity planning meetings.

Monitoring Scope

VMware Aria Operations is the main platform for performance, health, and capacity monitoring of the virtual infrastructure. It collects metrics from:

vCenter Servers

ESXi hosts

Virtual machines

Datastores

NSX-T Manager and related objects (if integrated)

Aria Operations stores time-series metrics and uses analytics to learn “normal” behaviour and highlight anomalies, issues, and risks.

Data Collection and Adapters

vCenter Adapter

Primary data source for ESXi, VMs, clusters, and datastores.

Collection interval: typically 5 minutes (can be tuned if needed).

NSX-T Adapter (if deployed)

Collects metrics for logical switches, routers, edges, and firewalls.

Other Management Packs (optional)

Additional packs can be added later (e.g. for physical hardware, backup, storage) to extend monitoring.

All collectors use authenticated service accounts with read-only or least-privilege roles defined in vCenter and NSX.

Dashboards and Views

Out-of-the-box dashboards in Aria Operations will be used as the baseline, for example:

vSphere Overview – overall health of clusters, hosts, and VMs

Capacity and Utilisation – CPU, memory, and storage trends

Troubleshooting Dashboards – detailed views for specific objects when investigating issues

Where needed, simple custom dashboards will be created to:

Group objects by site, cluster, or application

Show key KPIs for management (e.g. top 10 busy clusters, host contention, datastore usage)

KPIs and Thresholds

Key metrics monitored include:

Cluster / Host

CPU usage (%)

Memory usage (%)

Disk latency (ms)

Network throughput and packet drops

VM

vCPU ready time and CPU contention

Memory usage and ballooning / swapping

Disk latency and IOPS

Datastores (non-vSAN)

Capacity used / free

Disk latency and outstanding IO

Default Aria Operations alert definitions and dynamic thresholds are used, with adjustments where the environment has known baselines (for example, high but normal CPU usage in test clusters).

Alerts and Notification Flow

Alert Types

Health / performance alerts (e.g. high CPU, datastore latency)

Risk alerts (e.g. capacity exhaustion in 30 days)

Efficiency alerts (e.g. oversized or idle VMs)

Alert Routing

Alerts are grouped and forwarded to the central ticketing system (e.g. ServiceNow, Jira) using email or webhook integration.

Critical alerts (e.g. host down, cluster redundancy at risk) are tagged with higher severity for on-call escalation.

Noise Reduction

Non-actionable alerts (e.g. short, transient spikes) are tuned or disabled after an agreed review period.

Alert policies are scoped per object group (e.g. production vs. non-production) to avoid unnecessary tickets from lab systems.

Capacity and Planning

Aria Operations is used to support capacity planning:

Tracks consumption trends for CPU, memory, and storage

Identifies when clusters are predicted to run out of capacity based on observed growth

Provides simple “what-if” analysis to estimate impact of adding or removing hosts

Capacity reports are generated monthly and reviewed by the infrastructure team.

Reporting and Responsibilities

Daily

Operations team monitors key dashboards and new critical alerts.

Weekly

Review of recurring alerts and potential tuning / remediation.

Monthly

Capacity and performance summary report for management.

The infrastructure operations team owns Aria Operations dashboards and alert configurations, with change control for any major policy changes.

2. VMware Aria Operations for Logs – Monitoring Design

Aria Operations for Logs provides centralised log management for the environment. Instead of manually reviewing logs on individual ESXi hosts or vCenter Server, all system logs are forwarded into a single platform. This ensures that operational and security events are captured reliably and retained for the required duration.

The platform will receive logs from vCenter Servers, ESXi hosts, and other infrastructure components. Logs can include events such as authentication failures, service restarts, hardware warnings, VM lifecycle events, and any configuration changes. If the customer chooses to forward application logs from VMs, those can also be processed and indexed for troubleshooting purposes.

Once logs are ingested, they become searchable in real time. This enables engineers to quickly investigate incidents by filtering and correlating logs from different sources. For example, if a host becomes unresponsive, the platform can show related warnings from ESXi, vCenter’s task history, and any VM-level events around the same time. This reduces the time required to identify the root cause of issues.

Aria Operations for Logs also supports alerting based on log patterns. Alerts can be created to detect repeated authentication failures, storage-related warnings, host PSOD events, or any specific text patterns the customer wants to monitor closely. These alerts supplement the metric-based alerts from Aria Operations, providing more context around system behaviour.

Dashboards in Aria Operations for Logs present log data in an organised manner. Examples include dashboards for ESXi health events, vCenter errors, and security-related events. These dashboards help teams monitor the environment without having to run manual searches. Logs can be retained for 30, 90, or more days depending on compliance and storage policies. The retention period should match operational and auditing needs, as older logs are often required during incident investigation or compliance reviews.

By centralising all logs, the environment gains consistent visibility and much faster troubleshooting capabilities. Instead of connecting manually to each ESXi host, engineers can access an indexed, searchable history of system activity.

VMware Aria Operations for Logs – Monitoring Design
Monitoring Scope

VMware Aria Operations for Logs is the central log management and analysis platform. It collects logs from:

vCenter Servers

ESXi hosts (via syslog)

NSX-T components (Managers, Edges, T0/T1 gateways)

Aria Operations nodes

Optionally, other infrastructure devices and systems that support syslog (e.g. firewalls, load balancers, Linux VMs)

No vSAN log content is required in this design.

Log Collection and Ingestion

ESXi hosts and other syslog sources forward to Aria Operations for Logs using:

Standard syslog (UDP/TCP 514) or

Encrypted syslog (TCP 6514 / 1514) where required.

vCenter sends events, tasks, and alarms through its native integration.

Aria Operations sends events into Logs to link metrics and logs for end-to-end troubleshooting.

Log volume and EPS (events per second) are estimated to ensure the appliance is correctly sized for the environment.

Content Packs and Dashboards

Built-in content packs are used to provide ready-made dashboards, queries, and alerts for core platforms (e.g. vSphere, NSX, Aria Operations itself).

Custom dashboards will be created where needed to:

Show a “single pane” of critical logs for production

Highlight failed logins, configuration changes, and system errors

Provide quick filters by site, environment, or application tag

Log-Based Alerts

Aria Operations for Logs generates alerts when log patterns match known issues or error conditions, for example:

Repeated authentication failures

ESXi host connection failures

NSX component errors

vCenter or Aria Operations service issues

Alert notifications are integrated with the same central ticketing / notification system used by Aria Operations to keep workflows consistent.

Where possible:

Metric + Log Correlation is used (e.g. a CPU spike in Aria Operations plus related error logs in Operations for Logs) to speed up root-cause analysis.

Retention and Storage

Log retention period is defined based on:

Troubleshooting needs (e.g. 30–90 days online)

Any audit or compliance requirements (e.g. longer retention in cheaper storage or external archive)

The appliance storage is sized to keep the agreed retention without impacting performance. When storage usage nears thresholds, the operations team either expands storage or adjusts retention.

Responsibilities

Platform Owners

Ensure all required devices and systems send logs to Aria Operations for Logs.

Maintain parsing rules and log source configurations if new platforms are added.

Operations Team

Review log-based alerts daily.

Use dashboards for incident investigation.

Tune noisy or duplicate alerts in a controlled manner.

3. VMware Aria Operations for Networks – Monitoring Design

Aria Operations for Networks provides visibility into traffic flows, network dependencies, and communication paths across the virtual and physical network. This platform focuses on understanding how applications communicate, detecting abnormal traffic patterns, and mapping the end-to-end network path for any VM.

The system will connect to vCenter Server to discover virtual machines and their relationships to hosts and networks. It can also integrate with physical switches, routers, and firewalls through SNMP, API connections, or flow exports such as NetFlow or IPFIX. This allows it to build a combined view of both virtual and physical network components.

One of the primary benefits of Aria Operations for Networks is the ability to analyse traffic flows. It shows which VMs communicate with each other, the volume of data exchanged, and whether any unexpected or unauthorised flows occur. This is particularly useful for troubleshooting connectivity issues. For example, if a VM cannot communicate with a database server, the platform can display the full path between them, highlighting any firewall drops, misconfigurations, or latency issues.

The system also provides application-level visibility. Aria Operations for Networks can automatically identify application components based on their communication patterns and present them as a visual map. This helps teams understand dependencies and allows better planning for changes or migrations.

Performance monitoring is another important capability. The platform can highlight areas of the network experiencing packet loss, increased latency, or bandwidth congestion. These insights allow the network team to identify potential bottlenecks or misconfigurations before they affect users. If NSX-T is deployed, the platform can also show security group behaviour and suggest firewall rules based on real traffic patterns. This helps maintain a secure and efficient micro-segmentation policy.

Network alerts are generated when anomalies are detected. Examples include detection of unexpected inbound traffic, high latency between specific workloads, or sudden changes in communication patterns. These alerts allow the network team to act quickly and reduce the impact of issues.

Reports generated by Aria Operations for Networks include application dependency maps, firewall rule usage summaries, traffic volume reports, and network health assessments. These reports support regular operational reviews and help validate that the network is functioning as intended.

VMware Aria Operations for Networks – Monitoring Design

Monitoring Scope

VMware Aria Operations for Networks provides network visibility, flow analysis, and security posture monitoring across virtual and (optionally) physical networks.

In this design it is used to monitor:

NSX-T logical switches, routers, and edges

Traffic flows between VMs, tiers, and applications

Connectivity between on-premises data centres and cloud endpoints (if present)

Firewall and security rules (where integrated)

Data Sources and Collectors

Typical data sources:

vCenter Servers – inventory of VMs, port groups, and distributed switches

NSX-T Manager – logical networking, routing, and security rules

Physical devices (optional) – switches, routers, firewalls via SNMP, API, or flow exports

Collector/Proxy nodes are placed close to key data sources to reduce latency and minimise impact.

Dashboards and Visualisation

Default Aria Operations for Networks dashboards are used to provide:

Application Topology Views

End-to-end paths between application tiers

Identification of dependencies (e.g. web → app → DB)

Flow Analytics

Who is talking to whom, over which ports

East-west vs. north-south traffic patterns

Security Posture

Unused firewall rules

Potential micro-segmentation policies

These dashboards help to:

Validate network changes

Understand impact of outages or degraded links

Prepare for future segmentation or migration projects

Thresholds and Alerts

Aria Operations for Networks is configured to raise alerts for:

Loss of connectivity between key application components

Abnormal changes in traffic volume or patterns

NSX-T or network component health issues

Potential security issues, such as new unexpected flows or changes to policies

Conclusion

Monitoring a VMware environment effectively requires more than just collecting metrics or reviewing logs. You need a unified view that connects performance, events, and network behaviour. VMware Aria delivers exactly that through three tightly integrated components: Aria Operations, Aria Operations for Logs, and Aria Operations for Networks.

• Aria Operations shows how the environment is performing.
• Aria Operations for Logs shows what is happening behind the scenes.
• Aria Operations for Networks shows how everything communicates.

Together, they give operations teams the visibility they need to keep systems running smoothly, troubleshoot issues faster, and plan capacity with confidence. By using the full Aria suite, organisations can move from reactive firefighting to proactive management, reducing downtime and improving the overall stability of their environment.

Introduction

As virtualisation workloads expand, RAM alone can struggle to meet performance requirements. Starting with ESXi 8 Update 3, VMware now allows administrators to use NVMe SSDs as a memory tier, bridging the gap between volatile memory and persistent storage.

This feature can significantly boost performance, but setting it up isn’t always straightforward. Errors like “read-only file system” or “device already has an existing partition” are common when preparing NVMe drives.

In this post, I’ll walk you through a step-by-step configuration guide based on a real-world setup. You’ll see exactly how to clean, configure, and enable an NVMe device for memory tiering in ESXi 8 Update 3—while avoiding the common pitfalls.

Practical Tip: I used a Windows bootable USB stick, started the installer, and when prompted to choose an installation partition, I deleted all existing partitions. This ensured the NVMe drive was completely clean with no VMFS remnants before proceeding.

Step 1: Enable Memory Tiering in the Kernel

Before you can use any NVMe device as a memory tier, you need to enable memory tiering in the ESXi kernel:

esxcli system settings kernel set -s MemoryTiering -v TRUE

This allows ESXi to recognize NVMe storage as a valid memory tier candidate.

Step 2: Verify NVMe and Other Storage Devices

Next, confirm which devices are available on your host:

esxcli storage core path list

Typical output will show your NVMe device and any other storage. For example:

pcie.3a00-pcie.0:0-t10.NVMe____NVME_SSD_1TB____________________________0100000000000000
  Device Display Name: Local NVMe Disk
  Adapter: vmhba1
  Plugin: HPP
  State: active

This shows the NVMe is recognized but not yet configured as a tier device.

Step 3: Clean the NVMe Device

NVMe devices previously used for VMFS or other partitions often have leftover metadata. Attempting to create a tier device before cleaning will fail with errors like:

Selected device already has an existing partition. Aborting partition creation.

Make sure all datastores using the NVMe are unmounted. If the device is still claimed internally, a host reboot may be necessary to release any lingering claims.

Step 4: Create the NVMe Tier Device

Once the NVMe device is free of partitions and claims, create it as a tier device:

esxcli system tierdevice create -d /vmfs/devices/disks/t10.NVMe____NVME_SSD_1TB____________________________0100000000000000

If successful, ESXi now recognizes the NVMe as available for memory tiering.

Step 5: Set the Memory Tiering Percentage

Now configure what percentage of the host memory should be accelerated using the NVMe tier:

esxcli system settings advanced set -o /Mem/TierNvmePct -i 400

Note: The value must be a valid percentage (0–100). Using an invalid value like 600 or 800 will throw errors.

Step 6: Reboot the Host

Finally, reboot the ESXi host to apply all kernel and tiering changes:

reboot

After reboot, your NVMe device is now functioning as a memory tier, accelerating memory operations and improving performance for workloads that benefit from high-speed NVMe storage.

Tips and Gotchas

• Always unmount any datastore on the NVMe device before attempting to create a tier device.
• Tip I used Windows 11 installattion CD to deleted all the partions from the NVME drive
• If dd or partedUtil fail with read-only errors, it usually means ESXi still has an internal claim. A reboot is the cleanest fix.
• Check esxcli storage core path list to confirm the NVMe device is recognized and not in use.
• Only set /Mem/TierNvmePct after the tier device is created; otherwise, ESXi will throw a “bad parameter” error.

[root@localhost:~]   esxcli system settings kernel set -s MemoryTiering -v TRUE**
[root@localhost:~]         esxcli storage core path list
sata.vmhba0-sata.0:2-t10.ATA_____SAMSUNG_SSD_PM871a_2.5_7mm_256GB________S2XNNX0HA05452______
UID: sata.vmhba0-sata.0:2-t10.ATA_____SAMSUNG_SSD_PM871a_2.5_7mm_256GB________S2XNNX0HA05452______
Runtime Name: vmhba0:C0:T2:L0
Device: t10.ATA_____SAMSUNG_SSD_PM871a_2.5_7mm_256GB________S2XNNX0HA05452______
Device Display Name: Local ATA Disk (t10.ATA_____SAMSUNG_SSD_PM871a_2.5_7mm_256GB________S2XNNX0HA05452______)
Adapter: vmhba0
Controller: Not Applicable
Channel: 0
Target: 2
LUN: 0
Plugin: HPP
State: active
Transport: sata
Adapter Identifier: sata.vmhba0
Target Identifier: sata.0:2
Adapter Transport Details: Unavailable or path is unclaimed
Target Transport Details: Unavailable or path is unclaimed
Maximum IO Size: 33554432

pcie.3a00-pcie.0:0-t10.NVMe____NVME_SSD_1TB____________________________0100000000000000
UID: pcie.3a00-pcie.0:0-t10.NVMe____NVME_SSD_1TB____________________________0100000000000000
Runtime Name: vmhba1:C0:T0:L0
Device: t10**.NVMe____NVME_SSD_1TB____________________________0100000000000000**
Device Display Name: Local NVMe Disk (t10.NVMe____NVME_SSD_1TB____________________________0100000000000000)
Adapter: vmhba1
Controller: nqn.2014-08.org.nvmexpress_126f_NVME_SSD_1TB____________________________2020080100009
Channel: 0
Target: 0
LUN: 0
Plugin: HPP
State: active
Transport: pcie
Adapter Identifier: pcie.3a00
Target Identifier: pcie.0:0
Adapter Transport Details: Unavailable or path is unclaimed
Target Transport Details: Unavailable or path is unclaimed
Maximum IO Size: 262144
[root@localhost:~]         esxcli system tierdevice create -d /vmfs/devices/disks/t10.NVMe____NVME_SSD_1TB____________________
**0100000000000000

[root@localhost:~] esxcli system settings advanced set -o /Mem/TierNvmePct -i 400
[root@localhost:~]   reboot

so my NVME is here and ignore all the commands which I was trying to test to increse the memory it only take 400

After giving the above command reboot the esx host.

Here is a photo of booting for the first time

After the reboot

See it in action on my YouTube Channal

Login to the ESX and you can see the Memory 315 GB.

Proof that we are able to run vm ( btw I have enabled legacy CPU for this ESX8 server as I am using Intel NUC10 i7, which is not on the ESX8 Compatible list. )

At VMware Explore Las Vegas 2025, cybersecurity took center stage. With ransomware costs soaring and data breaches hitting even the largest global enterprises, Hock Tan and VMware leaders made one thing clear: cyber resilience is now a business survival issue, not just an IT responsibility.

The Rising Cost of Cyber Threats

The keynote highlighted how ransomware attacks and data leaks are redefining risk across every industry. Some sobering examples included:

Marks & Spencer: $440M lost after ransomware downtime crippled operations. Snowflake breach: A credential attack affecting 165 companies worldwide. U.S. Government Database leak: 2.9 billion records exposed, raising questions of national resilience.

These incidents underscore the stakes: one breach doesn’t just impact IT—it can destroy brand trust, erode customer confidence, and disrupt entire supply chains.

Introducing PCS Advanced Cyber Compliance

VMware’s answer is PCS (Private Cloud Services) Advanced Cyber Compliance—a new extension of the VMware Cloud Foundation platform designed to bake in resilience from day one.

Key capabilities include:

Multi-factor authentication & encryption: Protects data both at rest and in motion. Live patching & runtime protection: Vulnerabilities are addressed without downtime. Zero-trust security model: Assumes no implicit trust, enforcing strict access controls across every layer. vDefend & AVI Security: Deliver real-time visibility, intrusion detection, and web application protection. Continuous compliance enforcement: Ensures workloads meet regulatory standards (PCI, HIPAA, GDPR) automatically. Automated ransomware recovery: Detects, isolates, and recovers workloads while preserving compliance states.

This is security not as a bolt-on, but as a core design principle—reducing the need for endless third-party agents and tools.

Security vs. Agility – A False Trade-off

Traditionally, enterprises faced a painful choice: move fast or stay safe. Security was often seen as the blocker to innovation. VMware’s message at Explore 2025: those days are over.

With VCF 9.0 and PCS, organizations can now:

Deliver infrastructure “at the speed of the developer” with guardrails already in place. Scale AI workloads with built-in compliance enforcement. Automate disaster recovery to avoid the “all systems down” scramble.

Customer Perspective: Why This Matters

Enterprises like Barclays and Walmart shared how cyber resilience is not just IT hygiene—it’s essential for running mission-critical workloads.

Barclays: Needs PCI-compliant resilience as they scale AI workloads on-prem. Walmart: Operates thousands of global stores where downtime is simply not an option.

For both, PCS Advanced Cyber Compliance isn’t about passing audits—it’s about ensuring business continuity under pressure.

A New Era of Cyber Trust

Hock Tan closed this section with a reminder:

“Security is no longer a checkbox. It’s your license to operate.”

With PCS Advanced Cyber Compliance, VMware positions VCF 9.0 as the safest private cloud platform for enterprises navigating the age of ransomware. It provides not just protection but confidence—a foundation where IT can innovate without fear of compromise.

Key Takeaway

Cyber resilience is now business critical. With ransomware and breaches hitting harder than ever, VMware Cloud Foundation 9.0 delivers security by design, combining zero-trust principles, automated compliance, and rapid recovery.

For enterprises, this means fewer bolt-ons, faster operations, and a private cloud platform ready to withstand the threats of tomorrow.

Stay tuned for our next post in the series:

IT’s New Era – From Bottleneck to Business Enabler, where we explore how VCF 9.0 transforms IT teams into true partners in innovation.

VMware Kubernetes Service (VKS): Kubernetes Without the Complexity

One of the headline announcements at VMware Explore 2025 was the evolution of Kubernetes within VMware Cloud Foundation through the VMware Kubernetes Service (VKS).

For years, Kubernetes adoption has been hindered by complexity. Enterprises struggled with multi-cluster sprawl, uneven compliance, patching headaches, and the lack of operational expertise. VKS directly tackles these challenges by embedding Kubernetes as a fully managed, enterprise-grade service within vCF 9.0.

Why VKS Matters

Lifecycle Automation: VKS automates the full Kubernetes lifecycle—from cluster provisioning to patching, upgrades, and decommissioning—without requiring manual intervention. Consistency Across Environments: Whether running in a central data center, regional hub, or edge location, VKS provides a consistent operational model. Integrated Security: Security is enforced at the platform level, including RBAC, identity integration via Pinniped, network policies, and continuous compliance checks. Unified Developer Experience: Developers interact with Kubernetes the same way they would in the public cloud, but IT operations are unified and simplified under vCF.

Image suggestion: Screenshot or diagram of the VKS lifecycle workflow (cluster creation → monitoring → scaling → upgrade).

Developer Velocity at Scale

With VKS, developers can:

Spin up CNCF-compliant clusters directly through self-service portals or GitOps workflows. Use familiar toolchains such as VS Code, GitHub, Helm, and CI/CD pipelines without disruption. Seamlessly move between containerized workloads and traditional VMs on the same vCF platform.

Meanwhile, IT teams maintain centralized visibility and governance—ensuring developers move fast without creating compliance or security risks.

VKS in the Real World

Imagine a financial services company running trading apps and AI models side by side. With VKS:

Dev teams deploy microservices in Kubernetes for real-time transaction monitoring. Data teams spin up GPU-enabled clusters for AI-driven risk analysis. IT maintains audit trails, compliance enforcement, and disaster recovery policies automatically.

The result is not just agility, but confidence—something enterprises can’t afford to compromise.

Key Point on VKS: By embedding Kubernetes directly into vCF 9.0, VMware has eliminated the barriers to enterprise-scale adoption—turning what was once a fragmented, complex ecosystem into a streamlined, policy-driven service.

.

This unified approach reduces operational overhead while empowering organizations to focus on innovation, not integration.

Canonical – Ubuntu embedded into VCF

The partnership with Canonical, the company behind Ubuntu, was another major highlight. By directly embedding Ubuntu into vCF, VMware strengthens both performance and security for enterprise cloud-native environments.

Key benefits include:

Chiseled Containers: Minimal, purpose-built containers containing only essential components—reducing attack surface and improving security posture. vGPU-ready Infrastructure: AI/ML workloads can now run with native GPU drivers pre-integrated, making vCF the fastest path to AI-ready infrastructure. Long-Term Supported (LTS) Ubuntu Images: Enterprises get fully maintained, hardened Ubuntu releases supported by Canonical—eliminating patching and upgrade guesswork.

This collaboration ensures developers and IT teams benefit from the best of both worlds: VMware’s enterprise-grade infrastructure with Ubuntu’s cloud-native agility.

Empowering Developer Autonomy with IT Governance

One of the most important themes of the session was balance: developers need freedom to innovate, while IT needs control to maintain compliance and governance. VMware’s vCF delivers exactly that.

Robust multi-tenancy: Business units like legal, finance, engineering, and operations can each consume resources independently under central IT policy. Self-service consumption: Developers gain direct access to Kubernetes, VMs, storage, and networking resources without waiting for IT tickets. Policy-driven governance: IT admins can predefine guardrails while still enabling flexibility for developers.

Examples included services like:

Private AI as a Service – Secure access to AI images and toolchains, ready to deploy in private environments. Database-as-a-Service (DBaaS) – Pre-approved versions of Postgres, MySQL, and SQL Server delivered instantly with compliance controls.

Image suggestion: Demo screenshot showing developers launching Kubernetes + AI services from a self-service catalog.

This dual approach makes it possible for enterprises to move fast without breaking things—a recurring theme throughout the keynote.

Conclusion: A New Era of Cloud-Native Infrastructure

The message from VMware Explore was clear: Kubernetes isn’t just an add-on to vCF—it’s a first-class citizen. With seamless integration, CNCF compliance, Ubuntu collaboration, and AI-ready infrastructure, VMware is positioning vCF as the most secure, most complete, and easiest-to-manage private cloud platform for cloud-native workloads.

As organizations embrace containers, microservices, and AI-driven applications, vCF with Kubernetes and Ubuntu provides a future-proof foundation that scales without sacrificing security or governance.

Image suggestion: Closing keynote slide with “Cloud-Native at Scale” headline.

Key Takeaway: VMware is delivering a streamlined, enterprise-ready Kubernetes platform with vCF 9.0—uniting the developer’s need for speed with IT’s need for control.

Introduction

The energy inside the Venetian Expo Hall was undeniable as thousands of attendees gathered for the opening keynote at VMware Explore Las Vegas 2025. Broadcom’s President and CEO, Hock Tan, took the stage with a message that was both bold and forward-looking: the private cloud is not just the future—it’s the foundation of enterprise IT today.

Last year, Tan emphasized that private cloud would define the enterprise future. Fast-forward twelve months, and the vision has become reality. The numbers speak volumes: nine out of ten IT leaders now rank private cloud as their top strategic priority, reflecting a decisive industry shift. This isn’t about speculation—it’s about transformation that’s already underway.

With Broadcom’s deep engineering investments since the acquisition, VMware has delivered a fully integrated, software-defined platform that consolidates compute, networking, and storage into a single, unified SKU. The result is VMware Cloud Foundation 9.0 (VCF 9.0)—a platform that does not simply compete with public cloud but, in many cases, surpasses it.

Tan’s message was clear: VCF 9.0 is the enterprise standard for a new era—secure by design, developer-friendly by default, and built to deliver agility without compromise. It’s not just another release; it’s the culmination of 25 years of VMware innovation, reimagined for a world defined by AI, cyber resilience, and cloud-native scale.

The result? VCF 9.0 now outperforms public cloud—delivering stronger security, improved cost management, and unmatched control.

Breaking Down the Barriers

Tan highlighted three major friction points IT leaders face—and how VCF 9.0 solves them:

1. Developers vs. Infrastructure
   • Developers don’t want to manage infrastructure—they want velocity.
   • VCF 9.0 unifies containers and VMs, delivering “infrastructure at the speed of the developer.”
2. Siloed IT Teams
   • Networking, storage, compute, and security teams often speak different languages.
   • VCF 9.0 unites them under one seamless platform, accelerating app deployment and reducing operational complexity.
3. Security vs. Agility
   • Businesses often trade off speed for protection.
   • VCF 9.0 comes with integrated, built-in security tools, removing the need for endless add-ons.

Customer Spotlight: Barclays

Stephen Flaherty, Global Head of Infrastructure at Barclays, shared how VCF underpins their mission-critical systems. For Barclays, private cloud is “the lifeblood of all technology across the market.” With AI workloads rapidly emerging, they’re bullish on VCF 9.0 as the foundation to host AI models on-premises with the elasticity, compliance, and security of public cloud—delivered within their own environment.

Barclays’ engineers are already evolving into poly-skilled teams, benefiting from the unified approach. Flaherty described the rollout of VCF 9.0 as “the first time we expect our engineers to have a true public-cloud-like experience on-prem.”

Closing Notes: A 25-Year Journey, A New Beginning

As the keynote drew to a close, Hock Tan reminded attendees that VMware Cloud Foundation 9.0 is more than just a product launch—it is the culmination of 25 years of VMware innovation. From the early days of server virtualization to the rise of the software-defined data center, VMware has consistently redefined the enterprise technology landscape.

Tan underscored that VCF 9.0 is not just about running workloads; it’s about enabling IT leaders to step into a new role: becoming the heroes of their organizations. With this platform, IT is no longer confined to managing infrastructure—it becomes a driver of business value, resilience, and competitive advantage.

“We want to make you a hero—the person who drives huge impact in your organization.” – Hock Tan

The message was clear: VMware’s journey has always been about transformation, but VCF 9.0 is where transformation becomes empowerment. It gives developers the velocity they crave, provides enterprises the cyber resilience they demand, and offers IT teams the tools to lead with confidence.

What’s Next: Dive Deeper in Our Blog Series

This keynote recap is only the beginning. Over the coming days, we’ll be publishing four more in-depth blogs that expand on the key announcements and experiences from VMware Explore Las Vegas 2025:

1. Unleashing the Power of Kubernetes with vCF, vSphere, and Ubuntu
2. Cyber Resilience in the Age of Ransomware
3. IT’s New Era – From Bottleneck to Business Enabler
4. VMware Explore Fun & Games – Beyond the Keynotes

Together, this series will give you the full picture of VMware Explore 2025—from the groundbreaking technology shaping the future of private cloud, to the unique experiences that made the event unforgettable.

Stay tuned for Blog 2 tomorrow, where we take a deep dive into Kubernetes, vSphere, and Ubuntu integration inside vCF 9.0.

“We want to make you a hero—the person who drives huge impact in your organization.” – Hock Tan

Key Takeaway: VMware Cloud Foundation 9.0 isn’t just an upgrade—it’s a transformation. It breaks down silos, accelerates developer velocity, strengthens security, and provides a unified cloud experience that rivals (and in many cases, beats) public cloud.

Opening the Doors to Innovation & Connection

The Venetian Convention and Expo Center buzzed with excitement as Day 1 officially launched at VMware Explore 2025. Attendees dove right into a packed schedule of 140 sessions across four dynamic tracks, from cloud infrastructure and private AI to modern applications, networking, security, and load balancing.

A Centralized Hub for Learning, Networking & Relaxation

This year’s edition featured a newly expanded The Hub, a centralized area combining exhibitors, session spaces, and lounge zones. It housed everything from hands-on labs and the Expert Bar to sponsor booths, the Broadcast Booth (theCUBE), the Discovery Theater, Broadcom Rewards, and even the pop-up Bark Park for furry stress relief. The Communities Lounge served as a gathering place for vExperts, VMTN contributors, and others to make meaningful connections

Partner Power & Networking Lounge

Day 1 also emphasized collaboration. The Solution Provider and Distributor Partner Keynote, titled “Powering Growth in a VMware Cloud Smart World”, set the tone for partner engagement. Meanwhile, the Partner Lounge (Level 2, Bellini 2102) provided a space for more intimate networking and drop-in sessions VMware Blogs.

Evening Events: Welcome, Swag, and Hacking

Welcome Reception: The evening kicked off strong at 5:00 PM in The Hub (Hall C), hosted by diamond sponsors—Amazon Web Services, Google Cloud, Intel, and Microsoft. Attendees mingled over appetizers, drinks, and unforgettable moments with towering LED Robot Stilt Walkers. Full Event Pass holders picked up their official backpack and visited the VMware by Broadcom booth for T-shirts and goodies VMware Blogs.

Hackathon: Right after, the VMware {code} Hackathon ran from 7:00–11:45 PM in Ballroom C. A spirited, after-hours coding event welcoming both veterans and drop-ins—perfect for learning, competition, and community bonding VMware Blogs.

Looking Ahead to Day 2

Day 2 opens with a high-stakes General Session at 9:00 AM (Hall A), featuring insights on private cloud, AI, and accelerating application delivery—all from Broadcom and VMware leaders, plus customer stories. The session will be livestreamed with replay available in the video library

Meanwhile, the Hands-on Labs continue to offer immersive experiences:

• Expert-led workshops, 40+ self-paced labs (no pre-registration needed),
• VMware Odyssey tournaments, and tours of the Lab Room and Command Center Wall throughout the day. Plus, certification exam vouchers await Full Event Pass holders at the Exam Center VMware Blogs+9VMware Blogs+9VMware Blogs+9.

Why Day 1 Mattered

Final Thoughts

Day 1 set the stage brilliantly for an exhilarating week ahead. With thought-provoking showcases, immersive learning opportunities, and plenty of moments to connect and recharge, VMware Explore 2025 is clearly off to a stellar start. I’ll be around if you want to dive deeper into specific sessions, lab experiences, or catch up on video content!

I am delighted to share that I will be attending VMware Explore 2025 in Las Vegas for the very first time. What makes this experience even more special is that I have been invited through the VMware Bloggers Program. Having attended many VMware events in the past, this invitation feels like a true milestone—an opportunity to not only participate but also contribute as part of the official blogging community. Being recognized in this way is a moment of real pride for me, and I am looking forward to sharing my perspective on this exciting event.

Why VMware Explore 2025 Is Special

VMware Explore is more than a conference—it is the global hub for innovation, collaboration, and thought leadership in enterprise IT. This year, attendees can expect:

• Over 400 breakout sessions across Cloud Infrastructure, Private AI, Modern Applications, and Networking & Security.
• Opportunities to hear directly from VMware and Broadcom leaders in the General Session Keynote on Tuesday, August 26 at 9:00 a.m. PDT.
• Hands-on experiences through labs, certifications, and The Hub, offering both technical learning and valuable networking.
• In-depth discussions with experts and peers, covering real-world strategies for building and managing modern digital infrastructure.

For me, being part of this as a first-time attendee in Las Vegas makes it even more exciting.

Plan Ahead: The Session Scheduling Tool

With so much valuable content on offer, planning ahead is essential. The session scheduling tool is now live for Full Event Pass holders, allowing attendees to customize their agendas by track, session type, or speaker.

Scheduling early ensures you won’t miss out on the most popular sessions.

Explore the full session catalog here

My Must-Attend Sessions

Here are some of the sessions I’m most excited about, reflecting the breadth and depth of VMware Explore 2025:

Cloud Infrastructure

• Design and Architect: Best Practices for Deploying VMware Cloud Foundation 9.0
• VCF Evolution: PowerCLI, SDK, and API Enhancements
• Ask Me Anything About VMware Cloud Foundation Networking with NSX

Private AI

• Unlock Innovation with VMware Private AI Foundation with NVIDIA
• Ask Me Anything About Private AI Foundation

Networking, Security & Load Balancing

• From Zero to Hero: VMware vDefend Deployment Best Practices
• Security Reference Design for VMware Cloud Foundation

Modern Applications / Kubernetes

• All About Kubernetes on VMware Cloud Foundation
• Learn All About VMware vSphere Kubernetes Service

These are just a few highlights, but the full catalog offers much more to explore based on your specific interests.

Beyond the Conference: Enjoying Las Vegas

Attending VMware Explore in Las Vegas is not just about the sessions—it’s also about making memories in one of the most dynamic cities in the world. Known as the Entertainment Capital of the World, Las Vegas offers endless opportunities to relax and celebrate after a full day at the conference.

Here are a few highlights to make your trip memorable:

• The Las Vegas Strip: Famous for its dazzling lights, world-class hotels, and iconic landmarks like the Bellagio Fountains, the Eiffel Tower replica at Paris Las Vegas, and The Venetian’s Grand Canal.
• Shows & Entertainment: From Cirque du Soleil productions to headline concerts and magic shows, Vegas offers some of the best live entertainment anywhere.
• Culinary Experiences: The city is home to Michelin-starred restaurants, celebrity chef dining, and an incredible variety of global cuisines—from fine dining to indulgent buffets.
• Unique Attractions: Ride the High Roller observation wheel at The LINQ, explore the Neon Museum, or take a gondola ride at The Venetian.
• Day Trips: For those who want to venture beyond the city, the Grand Canyon and Red Rock Canyon offer breathtaking natural beauty just a short drive away.

Top Tips for First-Time Las Vegas Visitors

To make your trip as smooth and enjoyable as possible, here are a few practical tips:

• Stay Hydrated: The desert climate can be very dry, so carry water with you—even indoors, the air conditioning can be dehydrating.
• Comfortable Footwear: The Strip looks walkable but distances are much longer than they appear. Expect 10,000+ steps a day.
• Budget Smartly: Las Vegas offers everything from quick bites to luxury dining. Plan a mix so you can enjoy without overspending.
• Plan Transport: Walking, rideshares, and the monorail are the best ways to get around. Driving on the Strip can be time-consuming.
• Balance Work & Play: Build in time to enjoy the city outside of the conference—whether that’s an evening show, a poolside break, or sightseeing.

Final Thoughts

Being invited by the VMware Bloggers Program to cover this event is both an honor and a source of pride. Having attended several VMware events in the past, this feels truly special—not just because of the scale and energy of Explore Las Vegas, but because it represents an opportunity to share insights, amplify community voices, and contribute to a global conversation on innovation.

With VMware Explore beginning next Monday, now is the time to fine-tune your agenda and get ready for a week filled with knowledge, networking, and inspiration—not to mention the chance to enjoy everything that Las Vegas has to offer.

In 2025, the cloud isn’t just a place to run apps—it’s a key part of every company’s strategy. At first, the public cloud seemed perfect, offering unlimited growth, flexibility, and fast innovation. But now, many businesses are seeing the downsides: rising costs, slower performance, and strict data rules. That’s why more companies are starting to bring their workloads back on-premises or into hybrid cloud setups. It’s a quiet shift, but it’s changing everything.

Leading this movement is VMware Cloud Foundation (VCF) 9.0, Broadcom’s rearchitecture of the private cloud platform. So it is a lot more than just an upgrade, VCF 9.0 delivers a unified experience for virtual machines (VMs), containers, and AI workloads, offering unmatched automation, security, and cost control. Let’s explore why VCF 9.0 is a platform every modern enterprise should consider.

The Cloud Reset: Why Private Cloud Is Back

Today’s enterprise cloud reality is more complex than ever. While the public cloud offered agility and scalability, many organizations now face escalating cloud bills, unpredictable performance, and data residency concerns due to evolving global regulations. Broadcom’s latest research reveals that 69% of enterprises are actively repatriating workloads back to on-premises or sovereign cloud environments, driven by the need for cost control, governance, and operational consistency.

VMware Cloud Foundation 9.0 is Broadcom’s direct response to this shift. It enables enterprises to run modern workloads—including VMs, containers, and AI/ML pipelines—within a cloud-like environment deployed on-premises, at the edge, or within hybrid architectures that span hyperscalers and sovereign cloud partners. With native integration into platforms like Azure VMware Solution, Google Cloud VMware Engine, and AWS VMware Cloud, VCF 9.0 provides true workload mobility, allowing businesses to run applications wherever it makes the most economic or strategic sense.

Crucially, VCF 9.0 brings operational parity across environments. Whether workloads are on-premises or in the cloud, IT teams can use the same tools, policies, and automation frameworks to deploy, manage, secure, and optimize them. This eliminates the silos and complexity that traditionally plagued hybrid strategies. This consistency also helps organizations meet regulatory demands for data sovereignty while enabling innovation at the edge or in the public cloud.

In essence, VCF 9.0 offers the best of both worlds: the control and performance of on-premises infrastructure with the agility and scalability of the cloud. It’s not just about bringing workloads back—it’s about running them smarter, wherever they deliver the most value.

Unified Platform Architecture

One of VCF 9.0’s most powerful advantages is its single control plane architecture. This unifies every layer of the IT stack—compute, storage, networking, identity, security, and automation—into a cohesive, centrally managed platform. This approach not only eliminates infrastructure silos but also dramatically simplifies how environments are deployed, maintained, and scaled.

Through the new Operations Console and Quick-Start App, VCF 9.0 empowers IT teams to manage the entire cloud lifecycle—from Day-0 design to Day-1 deployment and Day-2 operations—from a single pane of glass. What once took days or weeks of coordinating across teams and toolsets can now be achieved in hours, with fewer errors, lower cost, and full compliance.

Key components of the unified control plane include:

• vSphere for abstracting and managing compute resources with deep VM and container integration.
• vSAN ESA (Express Storage Architecture) for delivering high-performance, cost-optimized storage with global deduplication.
• NSX with Enhanced Data Path for programmable, secure, and high-throughput networking across all tenants and workloads.
• VMware Aria (formerly vRealize) for cost visibility, performance optimization, workload insights, and lifecycle automation.

Efficiency and Performance Gains

VCF 9.0 delivers a transformative leap in efficiency and performance optimization, enabling enterprises to achieve significantly more with less. At the core of this improvement is advanced NVMe memory tiering, which intelligently prioritizes critical workloads across memory tiers, driving a 38% reduction in memory and server Total Cost of Ownership (TCO).

On the storage front, the adoption of vSAN ESA (Express Storage Architecture) with global deduplication offers up to 34% savings by eliminating redundant data and enabling smarter capacity utilization. Networking has also received a major upgrade, with the enhanced NSX datapath delivering up to 3x the throughput, reducing latency and CPU load while freeing up compute cycles for mission-critical applications. Notably, AI and GPU-driven workloads benefit from near-zero disruption thanks to vGPU vMotion, which enables seamless live migration of workloads without interrupting performance.

Together, these innovations allow organizations to maximize infrastructure ROI, reduce operational overhead, and scale intelligently—delivering cloud-level elasticity and performance within the efficiency bounds of a private cloud model.

A summary of the most exciting advancements in VCF 9.0’s efficiency and throughput:

• 38% lower memory and server TCO via NVMe memory tiering.
• 34% lower storage costs with vSAN ESA global deduplication.
• 3x better network performance with enhanced NSX datapath.
• Near-zero downtime for AI workloads with vGPU vMotion.

These features allow enterprises to run more workloads with fewer resources, leading to faster ROI and reduced overhead.

Built-In Security and Resilience

In VCF 9.0, security isn’t an afterthought; it’s intrinsically built into every layer of the stack. As cyber threats become more sophisticated, security must be foundational. VCF 9.0 embraces this philosophy by delivering a zero-trust architecture and operational resilience by design.

At the heart of VCF 9.0’s security strategy is the new Security Operations Dashboard, which provides IT and SecOps teams with real-time visibility into security posture, system compliance, and known vulnerabilities. With automated CVE tracking, compliance alerts, and guided remediation workflows, teams can now respond to emerging threats in minutes, not days.

VCF 9.0 also supports Confidential Computing, leveraging Intel TDX and AMD SEV-SNP to isolate workloads at the hardware level. This ensures that even privileged software cannot access sensitive memory regions. Combined with FIPS 140-2 validated encryption, STIG-compliant configurations, and TLS 1.3 support, VCF provides the cryptographic assurance required for regulated industries like finance, healthcare, and government.

Microsegmentation via vDefend enables fine-grained control over east-west traffic between workloads, drastically reducing the attack surface and containing lateral movement during a breach. Each tenant or workload can be automatically isolated into its own secure zone with just a few clicks.

Perhaps most critically, VCF 9.0 is built to defend against ransomware, one of the most urgent threats facing organizations today. With vSAN-to-vSAN replication, deep snapshot capabilities, and immutable backup support, VCF can help organizations recover rapidly from ransomware attacks without paying a ransom. Even in the event of encrypted or deleted data, organizations can restore clean, secure copies, minimizing business disruption and financial damage. Non-disruptive patching and in-place upgrades further reduce the operational gaps that attackers often exploit.

In essence, VCF 9.0 doesn’t just secure the infrastructure; it secures the business, offering peace of mind in an environment where a single breach can result in millions in losses and permanent brand damage.

Native Automation & Day 2 Operations Made Effortless

With VCF 9.0, Broadcom makes automation native, not optional. One of its most defining features is its native support for intelligent automation across the entire cloud lifecycle—from provisioning to optimization, from patching to reporting. Broadcom has moved away from fragmented tooling and stitched-together scripts; with VCF 9.0, automation is deeply integrated, intelligent, and essential.

At the core of this is the VCF Automation Console, a centralized hub that gives cloud administrators and DevOps teams a self-service interface to provision virtual machines, Kubernetes clusters, and entire infrastructure stacks on demand. Whether through the GUI or via API, teams can define reusable templates, enforce policies, and apply consistent configurations across environments—reducing manual effort and ensuring compliance by design.

The platform supports Infrastructure as Code (IaC), allowing organizations to automate deployments using familiar tools and workflows. Administrators can build, version, and manage cloud resources through APIs, JSON/YAML templates, or orchestration pipelines—speeding up developer onboarding, reducing human error, and eliminating bottlenecks in infrastructure delivery.

One of the most critical Day 2 capabilities in VCF 9.0 is fleet-wide configuration drift detection. Using VMware Aria integrations, the platform continuously monitors the desired state of infrastructure across hosts, clusters, and tenants, automatically flagging deviations that could introduce risk or instability. This enables proactive compliance enforcement and prevents issues before they impact production.

Automated patching and lifecycle management are now built-in capabilities, not complex, disruptive tasks. Whether managing three clusters or thirty, VCF 9.0 allows you to schedule, stage, and roll out patches, security updates, and version upgrades with minimal downtime, ensuring the platform stays secure and performant without interrupting business operations.

In addition to automation, operational efficiency is improved through enhanced tooling:

• The new VCF Installer UI offers a guided deployment experience, making greenfield and brownfield deployments faster, less error-prone, and easier to scale.
• The Operations Console offers chargeback and showback, identity and certificate management, diagnostics and telemetry, and role-based access control—giving infrastructure and FinOps teams the insights they need to optimize usage and costs.

Ultimately, VCF 9.0 transforms traditional infrastructure management into a cloud-like operating model—fast, programmable, resilient, and transparent. It frees teams from repetitive tasks, minimizes human error, and provides consistent operations at scale, from core data centers to the edge.

A Unified Platform for VMs, Kubernetes, and AI Workloads

In VCF 9.0, all workloads are treated equally—whether it’s a legacy ERP system, a stateless Kubernetes app, or an AI training pipeline.

VCF 9.0 redefines workload versatility by treating all application types—legacy or modern—as first-class citizens. Whether you’re running a monolithic ERP system, a containerized microservice, or a GPU-intensive AI pipeline, VCF 9.0 provides a consistent, performant, and secure foundation.

With embedded vSphere Kubernetes Service, organizations can deploy and manage Kubernetes natively alongside traditional VMs. The platform also offers Kubernetes-as-a-Service, enabling multi-tenant self-service environments ideal for internal teams or external customers. For AI-driven workloads, VCF 9.0 includes vGPU scheduling, live migration for GPU-backed workloads, and seamless integration with NVIDIA AI Foundation, allowing data scientists and ML engineers to run, train, and infer large models at scale—directly on-premises or in hybrid environments.

By consolidating infrastructure for VMs, containers, and AI under a unified control plane, VCF 9.0 empowers cloud-native developers, DevOps engineers, and AI/ML teams to innovate without the friction of siloed infrastructure. It’s a platform truly built for the future of computing.

Key capabilities:

• Embedded vSphere Kubernetes Service.
• Kubernetes-as-a-Service for multi-tenancy and self-service.
• Support for vGPU scheduling, AI inference, and Private AI workloads in containers or VMs.
• Tight integration with NVIDIA AI Foundation and GPU hardware.

This makes VCF 9.0 an ideal platform for cloud-native developers, DevOps teams, and data scientists alike.

Business Outcomes: Faster, Cheaper, Smarter

VCF 9.0 isn’t just a technical win—it’s a business accelerator. According to IDC and internal benchmarks, enterprises can expect a 61% acceleration in workload deployments, a 66% reduction in outage recovery time, and up to 40% cost savings compared to public cloud alternatives. Even more compelling, organizations using vSAN ESA can save up to $10 million over three years versus traditional storage solutions. VCF 9.0 empowers businesses with both control and agility—no trade-offs required.

Based on IDC and internal data, key business outcomes include:

• 61% faster workload deployments.
• 66% quicker recovery from outages.
• 40% cost savings vs. public cloud.
• Up to $10M saved over 3 years using vSAN ESA over traditional storage.

Enterprises no longer have to choose between control and agility. With VCF 9.0, they get both.

Ecosystem Support & Compatibility

To ensure seamless adoption and long-term scalability, VCF 9.0 is built with broad ecosystem compatibility at its core, reducing risk during upgrades and simplifying procurement across diverse environments. On the hardware front, it supports industry-leading vendors like Dell, HPE, Lenovo, and Supermicro, giving customers flexibility in choosing infrastructure that fits their needs. Processor support includes modern architectures like Intel Xeon and AMD EPYC, while older, less efficient CPUs such as Intel Skylake have been deprecated to promote a faster, leaner baseline.

VCF 9.0 is also cloud-ready, integrating with platforms like Azure VMware Solution, AWS, and Google Cloud, enabling true hybrid operations. For AI and ML workloads, NVIDIA-certified GPU compatibility ensures enterprises can harness advanced compute power natively. With built-in compliance for FIPS, STIG, and TLS 1.3, organizations operating in regulated industries can deploy confidently. This ecosystem-first approach makes VCF 9.0 a future-proof investment for both IT and procurement leaders.

Advanced Services Built on VCF 9.0

Beyond foundational infrastructure, VCF 9.0 introduces a new tier of advanced services that elevate it from a private cloud platform to a full-fledged application delivery engine.

• With Avi Load Balancer, organizations gain fine-grained Layer 7 traffic control, integrated WAF (Web Application Firewall), and global load balancing, empowering app teams to scale securely.
• Disaster Recovery is redefined with immutable snapshots and enhanced replication via vSAN-to-vSAN, ensuring ransomware resilience and faster recovery.
• The Data Services Manager (DSM) streamlines database provisioning for developers with policy-driven guardrails.
• vDefend delivers dynamic microsegmentation that adapts to tenant, workload, and traffic context in real time.
• Finally, the Private AI Foundation enables enterprises to run, fine-tune, and infer from large language models using certified GPU infrastructure—all from within their secure environment.

These capabilities turn VCF into not just a cloud platform—but a full application delivery engine.

Conclusion: Why VCF 9.0 Is a Must-Have

VMware Cloud Foundation (VCF) 9.0 represents a significant leap forward from VCF 5, transforming the platform from a primarily infrastructure-focused solution into a modern, workload-agnostic cloud operating model. While VCF 5 offered basic automation and support for traditional workloads, VCF 9.0 brings built-in Kubernetes-as-a-Service, native support for AI/ML workloads with vGPU scheduling, and deep integration with NVIDIA AI Foundation. It also drastically improves operational efficiency—offering 61% faster workload deployments and 66% quicker recovery from outages—while delivering up to 40% cost savings compared to public cloud. With vSAN ESA, businesses can save up to $10 million over three years versus traditional storage. In short, VCF 9.0 combines the control enterprises expect with the agility they need to compete in a cloud-smart world.

You can see a lot of changes in modernization of Infrastructure in VCF 9.0

The future of cloud is hybrid, sovereign, AI-ready, and developer-empowered. VCF 9.0 is the infrastructure layer built for that future. Whether you’re building AI apps, running mission-critical ERP workloads, or serving hundreds of tenants in a sovereign cloud—VMware Cloud Foundation 9.0 gives you the control of on-premises infrastructure with the power of the cloud.

If you’re someone who remembers the satisfying click of a floppy drive and has witnessed the grand evolution of enterprise IT, then you’ve seen the pendulum swing more times than a grandfather clock. We started with standard servers, then moved to converged infrastructure, consolidating components, only to further innovate with hyper-converged infrastructure (HCI), integrating compute, storage, and networking into elegant, software-defined packages. Just when it seemed like the cloud era meant everything would be public and remote, we’re now experiencing a fascinating “back to the future” moment: private cloud is making a serious comeback, and VMware Cloud Foundation (VCF) 9 is leading the charge. It’s leaner, smarter, and more powerful than anything we’ve seen before.

Public cloud often dominates the headlines, with its stories of massive scale, disruption, and sometimes, eye-watering costs. Yet, behind the scenes, a growing number of organizations are rethinking their approach. They’re looking inward, toward infrastructure they can control, tailor, and inherently trust.

Today’s private cloud isn’t about outdated servers and clunky dashboards. It’s a modern platform built with cloud-native principles, delivering:

• Predictable costs and performance: No more surprise bills or unpredictable resource contention.
• Full data control: Maintain sovereignty and compliance over your most sensitive information.
• Seamless automation and orchestration: Streamline operations and accelerate deployments.

Crucially, it provides the familiar cloud experience without the dreaded vendor lock-in or unexpected charges.

Goodbye Silos, Hello Full-Stack Thinking: A Cultural Shift

This resurgence of private cloud also shines a light on a persistent IT problem: team silos. In many enterprises, security teams rarely interact with infrastructure, developers are distant from network teams, and operations are often the last to know.

VMware Cloud Foundation (VCF) 9 fundamentally changes this dynamic by enforcing cross-functional collaboration. It encourages a new kind of engineer – someone who understands not just compute, but also networking, storage, automation, and containers. The days of narrow expertise are giving way to full-stack versatility. This isn’t about fixing printers anymore; it’s about managing Kubernetes clusters, secure overlays, and CI/CD pipelines in real-time.

VCF 9: More Than a Version Update

There’s been a lot of buzz about recent VMware changes, but beneath that noise lies a substantial technical evolution. VCF 9 isn’t just another incremental upgrade; it’s a foundation redesign that reshapes how infrastructure is deployed, secured, and maintained.

What sets it apart?

• Faster, cleaner deployments using refined workflows and automation.
• Tighter integration with Aria for intelligent monitoring and operational insights.
• Robust support for AI workloads with powerful data services and scalable performance.
• vSAN ESA, now fully mature, delivering incredible storage efficiency.
• Enhanced network edge capabilities supporting hybrid and distributed models.

This isn’t merely a patch; it’s a reimagining of what a private cloud platform can be—agile, scalable, and intelligent by default.

The Technical Edge: What’s Under the Hood of VCF 9

Let’s dig deeper into the technical elements that make VCF 9 such a powerful release:

1. Lifecycle Management Done Right

Every component—vSphere, NSX, vSAN, Aria—is governed by a curated Bill of Materials (BOM). The SDDC Manager handles upgrades, validations, and rollback workflows with minimal disruption. Even Day 2 operations, like SSL renewal or password rotation, are fully automated.

2. Network Virtualization That Scales

NSX overlays leverage Geneve encapsulation for high-performance, programmable networking. Each workload domain is isolated with its own NSX-T Manager cluster, and crucially, segmentation, routing, and security policies are completely decoupled from hardware.

3. Seamless Integration with Tanzu and Containers

VCF 9 allows you to deploy and manage Kubernetes clusters natively. You can easily use GitOps workflows for application delivery, enabling true platform engineering without the usual friction between development and operations teams.

4. Resilience and Recovery Built-in

Management and workload domains are separated for high availability. SDDC Manager backups are file-based and easily restorable, ensuring that even in the unlikely event of a control-plane failure, your infrastructure workloads remain online

VCF Licensing: What You Need to Know

While this blog focuses on the technical advancements of VCF 9, it’s important to clarify its licensing model. VMware Cloud Foundation (VCF) is generally not free for commercial use. Broadcom, the company that acquired VMware, has shifted its licensing model from perpetual licenses to a subscription-based model, with costs typically calculated per core.

However, there are specific scenarios where you can get free personal-use licenses for VCF:

• VMware Certified Professionals (VCPs): If you hold a VCP-VCF (Administrator/Architect) certification, you can often access free, personal-use VCF licenses for your home lab. This is usually tied to obtaining or maintaining your VCP certification.
• VMUG Advantage Members: VMUG (VMware User Group) Advantage members who pass the VCP-VCF certification exam can gain access to free, personal-use VCF licenses for up to three years, provided they maintain an active VMUG Advantage membership. This program specifically rewards certification success with exclusive tools for personal use.

It’s crucial to remember that these free licenses are strictly for personal, non-production use in a home lab environment. Unlike some individual VMware products (like Fusion and Workstation, which have recently become free for all users), this does not apply to VMware Cloud Foundation (VCF) for commercial purposes. Therefore, unless you meet the specific criteria for personal-use, home-lab licensing, VMware Cloud Foundation is a paid, subscription-based product.

Final Thoughts: Why Now Is the Right Time for Private Cloud

As digital transformation deepens and AI pushes the boundaries of what workloads demand, organizations need infrastructure that is flexible, efficient, and secure. That doesn’t always mean going public.

Private cloud has evolved, and VCF 9 is at the center of that transformation. Whether you’re running high-performance applications, managing sensitive data, or building modern platforms at scale, VCF 9 delivers the experience developers want, with the control enterprises need.

Ready to modernize your private cloud strategy? Comment below and share your insights!

VMware Explore is more than just a conference; it’s a pivotal event for anyone serious about their cloud journey, professional growth, and staying ahead in the ever-evolving IT landscape. And this year, it’s returning to the vibrant energy of Las Vegas from August 25-28, 2025, at The Venetian Convention and Expo Center! If you’ve been on the fence about attending, let me tell you why this is an opportunity you simply can’t afford to miss, and how to make the most of your experience.

Why Attend VMware Explore? Beyond the Buzzwords

VMware Explore offers an unparalleled blend of professional development, hands-on learning, and networking that can significantly accelerate your career and impact your organization’s success.

• Professional Experience and Learning: Dive deep into the latest innovations in multi-cloud, modern applications, security, networking, and private AI. With hundreds of technical sessions, expert-led workshops, and deep-dive discussions, you’ll gain practical, actionable insights directly from VMware and Broadcom experts. This is your chance to understand how to apply cutting-edge solutions to real-world scenarios, enhance your problem-solving skills, and even earn valuable certifications.
• First-Hand Experience: The renowned Hands-on Labs are a highlight, offering you the opportunity to test-drive VMware products and solutions in a live environment with no installation required. This immersive experience is invaluable for sharpening your skills and exploring new features before implementing them in your own environment.
• Networking with Peers and Customers: The “hallway track” is legendary for a reason! VMware Explore brings together IT professionals from diverse backgrounds and industries. This is your chance to connect with peers, share challenges, exchange war stories, and learn from how others are tackling similar issues. You’ll meet potential mentors, collaborators, and even future employers. Beyond peers, it’s also a fantastic opportunity to engage directly with VMware experts, partners, and even customers, building connections that can open doors to new opportunities and insights.

Preparing for Your Las Vegas Adventure: The Essential Steps

Attending a major conference like VMware Explore requires a bit of planning to ensure you maximize your learning and enjoyment.

1. Secure Your Spot: Booking the Event

The first and most crucial step is to register for VMware Explore. Don’t delay! Early bird pricing often offers significant savings, and popular pass types can sell out. The official website is your go-to for registration.

• Link to book the event: Keep an eye on the official VMware Explore website for registration details: https://www.vmware.com/explore/us.html

2. Lock Down Your Stay: Flights and Hotels

Las Vegas is a popular destination, and conference weeks see a massive influx of visitors.

• Flights: Book your flights as far in advance as possible to secure better rates and preferred travel times. Consider flying into Harry Reid International Airport (LAS).
• Hotels: Hotels, especially those near the convention center, can become expensive very quickly. The Venetian Convention and Expo Center is where VMware Explore will be held. Booking your hotel well in advance, ideally through the official event block if available, is highly recommended to secure discounted rates and proximity to the venue. Otherwise, explore options at nearby resorts like The Palazzo (connected to The Venetian), or other properties on the Strip.

3. Plan Your Learning Journey: Session Booking

Once registration opens and the content catalog drops, act fast to book your sessions! The most popular technical deep-dives and expert-led sessions fill up incredibly quickly, and you don’t want to be disappointed.

• Strategy: Browse the content catalog thoroughly. Prioritize sessions that align with your learning goals and professional development. Create a personalized schedule, and if a session is full, add yourself to the waitlist. This also helps event organizers identify highly demanded topics.
• Mobile App: Download the official VMware Explore mobile app as soon as it’s available. This will be your best friend for managing your schedule, seeing real-time room changes, and receiving important updates.

Beyond the Conference Walls: Experiencing Las Vegas

While learning is paramount, you’re in Las Vegas! Take advantage of the city’s unique offerings. The Venetian Convention and Expo Center itself offers fantastic facilities, including diverse dining options, but step out and explore!

• The Strip: A walk along the famous Las Vegas Strip is a must. Marvel at the themed resorts, from the Eiffel Tower at Paris Las Vegas to the iconic Bellagio Fountains and the Mirage Volcano.
• Sightseeing:
  • The High Roller Observation Wheel: For breathtaking panoramic views of the city.
  • The Neon Museum: A fascinating outdoor museum preserving iconic Las Vegas signs.
  • Area15: An immersive art and entertainment complex.
• Dining: Las Vegas boasts a world-class culinary scene. From celebrity chef restaurants to more casual but delicious options, there’s something for every taste and budget. Consider exploring restaurants within The Venetian complex, or venture further to discover hidden gems.
• Nightlife: After a day of intense learning, unwind and enjoy the vibrant Las Vegas nightlife. From high-energy nightclubs with top DJs to sophisticated lounges and incredible shows (think Cirque du Soleil!), Las Vegas offers endless options for evening entertainment.

Essential Travel Tips for a Smooth Trip

A little preparation goes a long way, especially when traveling for a major conference.

• Passport Check: If you are an international attendee, ensure your passport is valid for at least six months beyond your intended stay and check if you require a U.S. visa or an ESTA (Electronic System for Travel Authorization) well in advance. Visa processing times can be lengthy, so don’t leave this to the last minute.
• Multiple Plug Charger/Power Bank: You’ll be using your devices constantly for scheduling, note-taking, and networking. Don’t forget a multi-plug charger or a portable power bank to keep all your gadgets fueled throughout the day.
• Comfortable Shoes: This cannot be stressed enough! Convention centers are vast, and you’ll be doing a lot of walking. Prioritize comfortable footwear over fashion.
• Layers: Las Vegas weather can be unpredictable, and convention centers are often heavily air-conditioned. Pack layers – a light jacket or sweater will be your best friend.
• Stay Hydrated: The desert climate of Las Vegas can be dehydrating. Carry a reusable water bottle and refill it frequently at water stations around the venue.

VMware Explore Las Vegas is an investment in your future. By planning ahead and embracing both the learning opportunities and the city’s unique charm, you’re set for an incredibly rewarding and unforgettable experience. I look forward to seeing you there!
